Performance

Service ceiling 17000 ft (5200 m)
Maximum cruising speed at H=3000m 135 kts (250 km/h)
Economy speed at H=9800ft (3000m) 120 kts (220 km/h)
Maximum range (H=9800ft (3000m), 0.5 hour fuel reserve) 713 nm (1321 km)
Flight endurance (H=9800ft (3000 m), 0.5 hour fuel reserve) 6 h
Fuel consumption 14-16 g/h (38-43 kg/h)
Take-off run (SL, ISA) (water/ground) 1804/1017 ft (550/310 m)
Landing roll (SL, ISA) (water/ground) 984/1280 ft (300/390 m)
Seaworthiness, sea state 2 (1.64 ft (0.5 m) wave height)

Weights

Max take-off weight 5004 lbs (2270 kg)
Empty weight 3704 lbs (1680 kg)
Payload 849 lbs (385 kg)
Maximum fuel capacity 540 lbs (245 kg)

Dimensions

Length 34.94 ft (10.65 m)
Wing span 41.73 ft (12.72 m)
Overall height at rest 12.33 ft (3.757 m)
Wing area 270.18 sq.ft (25.1 sq.m)
Propeller diameter 6 ft (1.83 m)
Wheel track 7.46 ft (2.273 m)
Wheelbase 13.51 ft (4.118 m)

Cabin internal dimensions

Length 12 ft (3.65 m)
Height 4.035 ft (1.23 m)
Width 4.1 ft (1.25 m)
Luggage compartment volume 28.2528 cub.ft (0.8 cub.m)
Crew 1 (pilot)
Passengers 5
